Width [mm]
|
64,8 |
|
Length [mm]
|
107,3 |
|
Max. number of valve spaces
|
32 |
|
Valve island structure
|
Valve sizes mixable |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Control pressure [bar]
|
3 to 8 |
|
Corrosion resistant class KBK
|
3 - severe corrosion stress |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
170,00 |
|
Material information
|
RoHs compliant |
|
Max. number of valve coils
|
32 |
|
Nominal operating voltage DC [V]
|
24 |
|
Protection category
|
IP65 |
|
Information about protection category
|
In mounted condition |
|
Electrical connection 1, function
|
IO-Link |
|
Electrical connection 1, connection type
|
Plug |
|
Electrical connection 1, connection technology
|
M12x1, A coded to EN 61076-2-101 |
|
Electrical connection 1, number of pins / wires
|
5 |
|
End plate material
|
PPA reinforced |
|
Reverse polarity protection
|
for operating voltage |
|
installation position
|
arbitrary |
|
Diagnosis
|
Under-voltage Load supplies |
|
Intrinsic power input at load voltage [mA]
|
30 |
|
Intrinsic power input at operating voltage [mA]
|
30 |
|
Report
|
I-port |
|
Bearing temperature [°C]
|
-20 to 40 |
|
IO-Link, report
|
Device V 1.0 |
|
IO-Link, communication mode
|
COM2 (38,4 kBaud), COM3 (230,4 kBaud) |
|
IO-Link, port type
|
B |
|
IO-Link, number of ports
|
1 |
|
IO-Link, process data width OUT
|
1 - 4 Byte |
|
IO-Link, minimum cycle time
|
Device 3.2 ms |
|
LED display bus specific
|
1x Kommunikationsstatus |
|
Weight
|
170,00 g / Pcs |
|
GTIN
|
4052568224042 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal MPA-L (english) , Data sheet |
