Diagnose function
|
Display via LED |
|
installation position
|
arbitrary |
|
Short circuit resistance
|
yes |
|
Reverse polarity protection
|
For PLC plug S1 |
|
Repeatability
|
min. ±0.1 mm |
|
Analogue output
|
0 - 10 V |
|
Voltage supply requirement
|
Funktionskleinspannung mit sicherer Trennung (PELV) |
|
Debounce time inputs [ms]
|
3 |
|
Nominal operating voltage DC [V]
|
24 |
|
Power blackout bridging of logic voltage [ms]
|
10 |
|
residual ripple
|
4 Vss |
|
Power input in nominal operating voltage [mA]
|
20 to 30 |
|
Permitted voltage oscillations
|
± 25 % |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Relative humidity
|
95 % |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
0 to 55 |
|
Permission
|
RCM mark |
|
Product weight [g]
|
128 |
|
Linearity error FS [%]
|
0,2 |
|
Characteristic curves outputs
|
acc. to EN 61131-2 |
|
Characteristic curves inputs
|
acc. to EN 61131-2 |
|
Switching logic inputs
|
PNP (Positive switching) |
|
Switching logic outputs
|
PNP (Positive switching) |
|
Electrical connection: measuring system
|
M12 |
|
Electrical connection: PLC
|
M12 |
|
Fastening type
|
With throughway bores |
|
Housing material
|
PBT reinforced |
|
Weight
|
128 g / Pcs |
|
GTIN
|
4052568179878 |
|
Customs duty number
|
85437090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Standard cylinders DDPC, with measured-value transducer DADE (english) , Data sheet |
