Dimensions W x L x H
|
50 mm x 107 mm x 55 mm |
|
Diagnosis
|
Unterspannung |
|
Parameterising
|
Diagnoseverhalten |
|
Operating element
|
DIL switch |
|
LED displays
|
PL: Load supply |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 65 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Power blackout bridging [ms]
|
10 |
|
Potential separation channel - internal bus
|
Yes, for intermediate feed |
|
Potential separation channel - channel
|
no |
|
Corrosion resistant class KBK
|
(In integrated condition) |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
110,0 |
|
Max. address volume outputs [Byte]
|
32 |
|
Max. address volume inputs [Byte]
|
32 |
|
Report
|
IO-Link |
|
Max. line length
|
20 m |
|
electrical connection:
|
M12 |
|
Material information
|
RoHs compliant |
|
Housing material
|
PC |
|
IO-Link, report
|
Master V 1.0 |
|
IO-Link, communication mode
|
COM1 (4,8 kBaud), COM2 (38,4 kBaud), COM3 (230,4 kBaud) |
|
IO-Link, port type
|
AB |
|
IO-Link, number of ports
|
2 |
|
IO-Link, process data width OUT
|
Parameterisable 4/4 to 16/16 Bytes |
|
IO-Link, process data width IN
|
Parameterisable 4/4 to 16/16 Bytes |
|
IO-Link, minimum cycle time
|
Min. 1 ms per 1 Byte process data |
|
IO-Link Master, output current
|
1,6 A PL / Port |
|
Weight
|
110,0 g / Pcs |
|
GTIN
|
4052568255534 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) , Data sheet |
