Dimensions W x L x H
|
50 mm x 107 mm x 55 mm |
|
Parameterising
|
Systemparameter |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Typical 80 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Power blackout bridging [ms]
|
10 |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
140,0 |
|
Max. address volume outputs [Byte]
|
32 |
|
Max. address volume inputs [Byte]
|
32 |
|
Report
|
FHPP |
|
Material information
|
RoHs compliant |
|
Housing material
|
PC |
|
Fieldbus interface
|
1x socket M9, 5 pin |
|
Device specific diagnosis
|
Diagnose-Speicher |
|
Configuration support
|
MMI manual operating device |
|
Baud rate
|
1 Mbit/s |
|
LED display product specific
|
Error |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Total number of axes
|
4 |
|
Control interface
|
CAN bus |
|
Weight
|
140,0 g / Pcs |
|
GTIN
|
4052568208974 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX-CM-HPP (english) , Data sheet |
