Dimensions W x L x H
|
71 mm x 110 mm x 38.25 mm |
|
Diagnosis
|
Under-voltage Load supplies |
|
installation position
|
arbitrary |
|
Max. number of valve spaces
|
8 |
|
Reverse polarity protection
|
for operating voltage |
|
Baud rate
|
38,4 kBit/s, 230,4 kBit/s |
|
Operating voltage range DC electronics / sensor [V]
|
18 to 30 |
|
Operating voltage DC load voltage [V]
|
21.6 to 26.4 |
|
Intrinsic power input at load voltage [mA]
|
700 |
|
Intrinsic power input at operating voltage [mA]
|
35 |
|
Nominal operating voltage DC load voltage
|
24 V |
|
Nominal load voltage DC [V]
|
24 |
|
Nominal operating voltage DC [V]
|
24 |
|
Report
|
I-port |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Relative humidity
|
93 % |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
200,0 |
|
IO-Link, connection technology
|
Device 5 pin |
|
IO-Link, report
|
Device V 1.0 |
|
IO-Link, communication mode
|
COM2 (38,4 kBaud), COM3 (230,4 kBaud) |
|
IO-Link, port type
|
B |
|
IO-Link, number of ports
|
1 |
|
IO-Link, process data width OUT
|
2 Bytes |
|
IO-Link, minimum cycle time
|
Device 3.2 ms |
|
LED display bus specific
|
1x Kommunikationsstatus |
|
LED display product specific
|
16x Ventilstatus |
|
Cover material
|
PA |
|
Material information
|
RoHs compliant |
|
Weight
|
200,0 g / Pcs |
|
GTIN
|
4052568240349 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CTEU (english) , Data sheet |
