Valve function
|
2/2 closed monostable |
|
Operating pressure [bar]
|
0 to 0.5 |
|
Nominal width [mm]
|
0,8 |
|
Dispensing needle nominal width [mm]
|
1,00 |
|
Pitch dimension [mm]
|
9 |
|
Sealing principle
|
Soft |
|
installation position
|
arbitrary |
|
Reset mode
|
Mechanical spring |
|
Control type
|
Direct |
|
Power-on time
|
100% |
|
Max. electrical power consumption [W]
|
1,8 |
|
Nominal operating voltage DC [V]
|
24 |
|
Permitted voltage oscillations
|
± 10 % |
|
Operating medium
|
Fluid media |
|
Information about operating and control medium
|
Pay attention to the resistance of the materials in contact with media |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Bearing temperature [°C]
|
5 to 40 |
|
Medium temperature [°C]
|
5 to 50 |
|
Protection category
|
IP30 |
|
ambient temperature [°C]
|
5 to 40 |
|
Product weight [g]
|
18 |
|
electrical connection:
|
2-wire |
|
Cable length [MTR]
|
0,15 |
|
Wire ends
|
Unshielded |
|
Conductor nominal cross-section (AWG)
|
AWG28 |
|
Fastening type
|
with female threads and centring sleeve |
|
Fluid connection
|
UNF1/4-28 |
|
Information on fluid connection
|
Fitting for hoses with 3 mm outside diameter included |
|
Dispensing needle material
|
High-alloyed stainless steels |
|
Dispensing needle material number
|
1.4301 |
|
Material information
|
LABS containing materials included |
|
From medium contacting materials
|
ETFE |
|
Actuation type
|
Electrical |
|
Weight
|
18 g / Pcs |
|
GTIN
|
4052568296681 |
|
Customs duty number
|
84248970 |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VTOE (english) |
|
Document
|
Data sheet |
