Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Switching position display
|
no |
|
Power-on time
|
100% |
|
Insulation material class
|
H |
|
Coil characteristic value
|
230 V DC: 7 W |
|
Permitted voltage oscillations
|
-15 % / +10 % |
|
ATEX gas category
|
II 2G |
|
Ex ignition protection type gas
|
Ex db IIC T6, T5, T4 Gb |
|
ATEX dust category
|
II 2D |
|
Ex ignition protection type dust
|
ExtbIIICT85°C,T95°C,T130°C Db |
|
Ex protection approval outside of the EU
|
EPL Gb (BR) |
|
Ex ambient temperature
|
T4,T130°C:-50°C<=Ta<=+90°C |
|
Certified awarding point
|
BVS15ATEXE135 |
|
CE certificate (see declaration of conformity)
|
to EU EX protection directive (ATEX) |
|
Corrosion resistant class KBK
|
4 - particularly severe corrosion stress |
|
Protection category
|
IP65 |
|
Product weight [g]
|
1.700 |
|
electrical connection:
|
Terminal boxes, Cable feed in thread M20x1,5 |
|
Material information
|
LABS containing materials included |
|
Solenoid material
|
Aluminium wrought alloy |
|
Weight
|
1.700 g / Pcs |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
