Nominal operating voltage DC [V]
|
24 |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
590 |
|
Material information
|
RoHs compliant |
|
Switch on valve terminals
|
Type 44, VTSA |
|
Diagnosis
|
Unterspannung Ventile |
|
Max. number of valve spaces
|
16 for bistable valves |
|
LED displays
|
1 Sammeldiagnose |
|
Parameterising
|
Failsafe per channel |
|
Fuse (short circuit)
|
Internal electronic fuse Per valve outlet |
|
Operating voltage range DC [V]
|
21.6 to 26.4 |
|
Intrinsic power input at operating voltage
|
Type 15 mA (operating voltage supply electronics) |
|
Max. power supply per channel
|
0.2 A |
|
Max. cumulative currents per module [A]
|
4 |
|
Potential separation channel - internal bus
|
Yes, for additional feed |
|
Electrical controls
|
Fieldbus |
|
electrical connection:
|
over CPX |
|
Cover material
|
PA |
|
Housing material
|
Aluminium die casting |
|
Weight
|
590 g / Pcs |
|
GTIN
|
4052568007294 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal VTSA / VTSA-F (english) , Data sheet |
