Stroke [mm]
|
40 |
|
Piston diameter
|
80 mm |
|
Dampening
|
P: Elastic silencer rings / plates double-sided |
|
installation position
|
arbitrary |
|
Principle of operation
|
single action |
|
Construction set up
|
Piston |
|
Position detection
|
For proximity switch |
|
Variants
|
One-sided piston rod |
|
Anti-twist lock / guide
|
Flattened piston rod |
|
Operating pressure [bar]
|
1 to 10 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
0 to 60 |
|
Impact strength [N]
|
13.300 |
|
Product weight [g]
|
5.350 |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection
|
G1/8 |
|
Material information
|
Copper and PTFE-free |
|
Cover material
|
Aluminium |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium |
|
Piston rod material
|
High-alloyed stainless steels |
|
Roller material
|
Steel |
|
Permitted shear force during switching process [N]
|
4.000 |
|
Weight
|
5.350 g / Pcs |
|
GTIN
|
4052568137311 |
|
Customs duty number
|
84123100 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: STAF (english) , Data sheet |
