Design
|
Angular |
|
Based on standard
|
EN 60947-5-2 |
|
Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
ATEX dust category
|
II 1D |
|
Ex ignition protection type dust
|
Ex ia IIIC T135°C Da |
|
Ex protection approval outside of the EU
|
EPL Da (IEC-EX) |
|
Ex ambient temperature
|
see ATEX Certificate |
|
Material information
|
LABS containing materials included |
|
Measurement principle
|
Inductive |
|
ambient temperature [°C]
|
-25 to 70 |
|
Control output
|
Contactless 2-wire |
|
Switching element function
|
NO contact |
|
Max. switching frequency [hz]
|
500 |
|
Max. output current DC [mA]
|
100 |
|
Operating voltage range DC [V]
|
6 to 60 |
|
Electrical connection: input
|
M12x1 |
|
installation position
|
arbitrary |
|
Product weight [g]
|
70 |
|
Housing material
|
PBT |
|
Screws material
|
High-alloyed stainless steels |
|
Switching status indicator
|
LED yellow |
|
Bearing temperature [°C]
|
-25 to 70 |
|
Protection category
|
IP67 |
|
Shock resistance
|
Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
|
Oscillation strength
|
Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
|
Degree of contamination
|
3 |
|
Voltage drop [V]
|
<= 6 V |
|
Residual current [mA]
|
0 to 1 |
|
Reverse polarity protection
|
for all electrical connections |
|
Minimum load current
|
4 mA |
|
Weight
|
70 g / Pcs |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SRBG (english) , Data sheet |
