Material information
|
RoHs compliant |
|
Measured parameter
|
Relative pressure |
|
Measurement process
|
Pneumatic electric pressure converter |
|
Operating pressure [bar]
|
-1 to 10 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible |
|
Control output
|
Contact |
|
Switch function
|
Threshold value with fixed hysteresis |
|
Switching element function
|
changeover contact |
|
Switch on point [bar]
|
0,25 |
|
Maximum switch on point [bar]
|
0,4 |
|
Switch off point minimum [bar]
|
0,05 |
|
Max. output current DC [mA]
|
1.000 |
|
Minimum load current
|
2 mA at 24 V |
|
Short circuit resistance
|
no |
|
Operating voltage range DC [V]
|
21.6 to 26.4 |
|
Reverse polarity protection
|
no |
|
electrical connection:
|
M12x1 |
|
Fastening type
|
Screwable |
|
Pneumatic connection
|
G1/8 |
|
Housing material
|
Steel |
|
Electrical connection: material
|
POM |
|
Setting options
|
Fixed setting |
|
Protection category
|
IP65 |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Weight
|
90 g / Pcs |
|
GTIN
|
4052568255626 |
|
Customs duty number
|
85369095 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SPBA (english) , Data sheet |
