Complies to standard
|
EN 60947-5-2 |
|
Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
Copper and PTFE-free |
|
Measurement switching distance [mm]
|
1,5 |
|
Reduction factors
|
Steel pc. 37 = 1.0 |
|
ambient temperature [°C]
|
-25 to 70 |
|
Control output
|
PNP |
|
Switching element function
|
NC contact |
|
Max. switching frequency [hz]
|
4.500 |
|
Short circuit resistance
|
Cycling |
|
Operating voltage range DC [V]
|
10 to 30 |
|
Empty run current [mA]
|
<= 10 mA |
|
Reverse polarity protection
|
for all electrical connections |
|
electrical connection:
|
3-wire |
|
Cable length [MTR]
|
7,5 |
|
Cable sleeve material
|
TPE-U(PU) |
|
size
|
Slot 8 |
|
Fastening type
|
Insertable from above into the slot |
|
Housing material
|
PA |
|
Switching status indicator
|
LED yellow |
|
Protection category
|
IP65 |
|
Max. output current [mA]
|
150 |
|
Design
|
For T-slot |
|
Repeatability at constant conditions
|
<= 0.05 mm, side approaching |
|
Connection outlet direction
|
along |
|
Test conditions line
|
Bending radius strength to Festo standard |
|
Line properties
|
Standard+cable track |
|
Ambient temperature for moving cable placements [°C]
|
-5 to 70 |
|
Insulation voltage [V]
|
50 |
|
Surge voltage strength [kV]
|
0,8 |
|
Degree of contamination
|
3 |
|
Weight
|
100 g / Pcs |
|
GTIN
|
4052568094881 |
|
Customs duty number
|
85365019 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SIES-8M (english) , Data sheet |
