Complies to standard
|
EN 60947-5-2 |
|
Permission
|
C-tick |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
Copper and PTFE-free |
|
Measurement switching distance [mm]
|
4 |
|
Secured safety distance [mm]
|
3,24 |
|
Reduction factors
|
aluminium = 0,4 |
|
ambient temperature [°C]
|
-25 to 70 |
|
Repeatability at constant conditions
|
0.2 mm |
|
Control output
|
NPN |
|
Switching element function
|
NC contact |
|
Hysteresis [mm]
|
<= 0,36 mm |
|
Max. switching frequency [hz]
|
2.500 |
|
Max. output current [mA]
|
200 |
|
Voltage drop [V]
|
<= 2 V |
|
Inductive protection circuit
|
Integrated |
|
Short circuit resistance
|
Cycling |
|
Operating voltage range DC [V]
|
10 to 30 |
|
residual ripple
|
± 10% |
|
Empty run current [mA]
|
<= 10 mA |
|
Reverse polarity protection
|
for all electrical connections |
|
electrical connection:
|
M12x1 |
|
size
|
M12 |
|
Fastening type
|
With locking nut |
|
Integration type
|
flush |
|
Product weight [g]
|
30 |
|
Housing material
|
PBTP |
|
Switching status indicator
|
LED yellow |
|
Ambient temperature for moving cable placements [°C]
|
-5 to 70 |
|
Protection category
|
IP65 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Weight
|
30 g / Pcs |
|
GTIN
|
4052568069636 |
|
Customs duty number
|
85365019 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Proximity sensors SIE (english) , Data sheet |
