CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Measured parameter
|
Relative pressure |
|
Measurement process
|
Pneumatic electric pressure converter |
|
Operating pressure [bar]
|
1 to 10 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-20 to 80 |
|
ambient temperature [°C]
|
-20 to 100 |
|
Switching element function
|
changeover contact |
|
Max. switching frequency [hz]
|
3 |
|
Max. switch off voltage AC [V]
|
250 |
|
Max. switch off voltage DC [V]
|
250 |
|
Max. output current [mA]
|
4.000 |
|
electrical connection:
|
4 pin |
|
Fastening type
|
Screwable |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
G1/4 |
|
Product weight [g]
|
138 |
|
Housing material
|
Zinc plated steel |
|
Settings range threshold value [bar]
|
1 to 10 |
|
Protection category
|
IP65 |
|
Pressure measurement range [bar]
|
1 to 10 |
|
Operating voltage range DC [V]
|
12 to 250 |
|
Diaphragm material
|
NBR |
|
Weight
|
138 g / Pcs |
|
GTIN
|
4052568126544 |
|
Customs duty number
|
85369095 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: PEV/VPEV (english) |
|
Document
|
Data sheet |
