Operating voltage range DC [V]
|
0 to 30 |
|
Operating voltage range AC [V]
|
0 to 30 |
|
Current carrying capacity at 40°C [A]
|
4,0 |
|
Surge voltage strength [kV]
|
0,8 |
|
Protection category
|
IP67 |
|
ambient temperature [°C]
|
-25 to 85 |
|
Material information
|
RoHs compliant |
|
Degree of contamination
|
3 |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Housing material
|
PA |
|
Plug contacts material
|
brass, Gold plated |
|
Complies to standard
|
EN 61076-2-104 |
|
Connection frequency
|
100 |
|
Cable output
|
straight |
|
Product weight [g]
|
9,1 |
|
Electrical connection 1, design
|
round |
|
Electrical connection 1, connection type
|
Plug |
|
Electrical connection 1, connection technology
|
M8x1, A coded to EN 61076-2-104 |
|
Electrical connection 1, number of pins / wires
|
4 |
|
Electrical connection 1, fastening type
|
Screw lock with SW9 |
|
Electrical connection 2, connection technology
|
Screw clamp |
|
Cable diameter [mm]
|
3.5 to 5 |
|
Conductor - nominal cross-section [mm²]
|
0.14 to 0.5 |
|
Information about protection category
|
In mounted condition |
|
Housing colour
|
#000000 |
|
Screw lock material
|
brass, nickel-plated |
|
Weight
|
9,1 g / Pcs |
|
GTIN
|
4052568061289 |
|
Customs duty number
|
85366990 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: NECU (english) , Data sheet |
