Operating voltage range DC [V]
|
0 to 30 |
|
Current carrying capacity at 40°C [A]
|
1,5 |
|
Protection category
|
IP40 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Material information
|
RoHs compliant |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Housing material
|
PBT reinforced |
|
Plug contacts material
|
Bronze |
|
Complies to standard
|
EN 60603-13 |
|
Connection frequency
|
50 |
|
Cable output
|
straight |
|
Product weight [g]
|
5,0 |
|
Electrical connection 1, design
|
Angular |
|
Electrical connection 1, connection type
|
socket / container / …. |
|
Electrical connection 1, connection technology
|
Wiring diagram FC |
|
Electrical connection 1, number of pins / wires
|
40 |
|
Electrical connection 1, fastening type
|
Ratcheting lock |
|
Electrical connection 2, connection technology
|
Crimp terminal |
|
Conductor - nominal cross-section [mm²]
|
0,13 |
|
Conductor nominal cross-section (AWG)
|
AWG26 |
|
Weight
|
5,0 g / Pcs |
|
GTIN
|
4052568058654 |
|
Customs duty number
|
85366990 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal MPA-L (english) , Data sheet |
