Materials:
Body: anodized aluminium and plastic, internal parts: aliminium, stainless steel and brass, seal: NBR
Temperature range:
-10°C to +70°C
Operating pressure:
3 - 10 bar (pulse valve: 2 - 10 bar)
Control voltages:
Standard: 24 V=, 230 V AC, upon request: other voltages
Power consumption:
Direct current: 4.2 W, alternating current: 4.0 VA (draw: 7.0 VA)
Protection class:
IP 65
Solenoid:
N (plug size 1)
Function:
3/2-way version vented in the spring chamber of the actuator, therefore an exhaust air flow control is not possible. For 5/2-way version, an exhaust air flow control (speed controller) is possible with help from 2 piece flow control silencer
. Please order the flow control silencer separately.
Information:
These valves are generally delivered with coils and plugs!
|
Control voltage
|
48 V= |
|
function
|
3/2-way (spring return) |
|
Thread
|
G 1/4" |
|
Resetting by
|
Pneumatic spring |
|
flow [l/min]
|
780 |
|
Operating pressure [bar]
|
3 - 10 |
|
Weight
|
0 g / Pcs |
|
GTIN
|
4050571442309 |
|
Customs duty number
|
84812090 |
|
Manufacturer
|
Airtec |
|
YouTube Video
|
NAMUR valves |
