Model series
|
MS |
|
size
|
9 |
|
Construction set up
|
Fibre filter |
|
Filter porosity [Mikrometer]
|
0,01 |
|
Condensate drain
|
Manually cycling |
|
Operating pressure [bar]
|
2 to 12 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [6:8:4] |
|
Air purity class at the output
|
Compressed air to ISO 8573-1:2010 [1:7:2] |
|
Max. normal flow for air purity class [l/min]
|
7.800 |
|
Min. normal flow for air unit class [l/min]
|
390 |
|
Filter effective degree [%]
|
99,9999 |
|
Max. condensate amount [ml]
|
225 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
5 to 60 |
|
ambient temperature [°C]
|
5 to 60 |
|
Bearing temperature [°C]
|
-10 to 60 |
|
Residual oil content [Millgramm ]
|
0,01 |
|
Fastening type
|
pipe installation |
|
installation position
|
vertical ± 5° |
|
Pneumatic connection 1
|
G3/4 |
|
Pneumatic connection 2
|
G3/4 |
|
Housing material
|
Aluminium die casting |
|
Cover material
|
PA |
|
Filter material
|
Borosilicate fibre |
|
Clamps material
|
Aluminium wrought alloy |
|
Window material
|
PA |
|
Seals material
|
NBR |
|
Product weight [g]
|
2.500 |
|
Weight
|
2.500 g / Pcs |
|
GTIN
|
4052568195052 |
|
Customs duty number
|
84213925 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Filters, MS series (english) |
|
Document
|
Data sheet |
