size
|
12 |
|
Model series
|
MS |
|
installation position
|
vertical ± 5° |
|
Condensate drain
|
Fully automatic |
|
Construction set up
|
Centrifugal separator |
|
Max. condensate amount [ml]
|
400 |
|
Clamp protection
|
Integrated as metal bowl |
|
Degree of condensate discharge [%]
|
99 |
|
Operating pressure [bar]
|
2 to 12 |
|
Max. normal flow [l/min]
|
40.000 |
|
Normal nominal flow [l/min]
|
25.000 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
5 to 60 |
|
Air purity class at the output
|
Compressed air to ISO 8573-1:2010 [7:7:4] |
|
Medium temperature [°C]
|
5 to 60 |
|
ambient temperature [°C]
|
5 to 60 |
|
Product weight [g]
|
6,3 |
|
Fastening type
|
pipe installation |
|
Cover material
|
PA reinforced |
|
Swirl disc material
|
POM |
|
Material information
|
RoHs compliant |
|
Connection plate material
|
Aluminium die casting |
|
Mounting bracket material
|
Aluminium die casting |
|
Housing material
|
Aluminium die casting |
|
Module connector material
|
Aluminium die casting |
|
Clamps material
|
Aluminium wrought alloy |
|
Clamp seal material
|
NBR |
|
Window material
|
PA |
|
Dividing plate material
|
POM |
|
Weight
|
6,3 g / Pcs |
|
GTIN
|
4052568257293 |
|
Customs duty number
|
84818079 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet , Group data sheet: Wasserabscheider, Baureihe MS |
