Exhaust function
|
Can be throttled |
|
Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Hand assist actuation
|
Ratcheting |
|
Construction set up
|
Piston seat |
|
Reset mode
|
Mechanical spring |
|
Control type
|
pilot operated |
|
Control air supply
|
Internal |
|
Flow direction
|
Not reversible |
|
Valve function
|
2/2 |
|
Switching position display
|
With Accessories |
|
Operating pressure [bar]
|
3 to 16 |
|
Normal nominal flow [l/min]
|
25000 to 42000 |
|
Power-on time
|
100% |
|
Coil characteristic value
|
42 V AC: 50 Hz, pull-in power 14.0 VA, holding power 10.0 VA |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [-:-:-] |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
-10 to 50 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-10 to 50 |
|
Product weight [g]
|
3.800 |
|
electrical connection:
|
acc. to DIN EN 175301-803 |
|
Signal condition display
|
With Accessories |
|
Fastening type
|
pipe installation |
|
Pneumatic connection 1
|
Battery module |
|
Pneumatic connection 2
|
Battery module |
|
Material information
|
Copper and PTFE-free |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium die casting |
|
Weight
|
3.800 g / Pcs |
|
GTIN
|
4052568179700 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
|
Document
|
Group data sheet: Switch on/pressure build-up valves, model series MS |
