installation position
|
arbitrary |
|
Display of active target value
|
LED yellow |
|
Operation-readiness display
|
LED green |
|
Operating voltage range DC [V]
|
20 to 30 |
|
Input resistance extreme target value input
|
Typ. 100 kOhm |
|
Input resistance target value input [Kilo-Ohm]
|
3 |
|
Adjustable output voltage [V]
|
0 to 10 |
|
Power consumption at 24 V DC [W]
|
1,5 |
|
Max. output current [mA]
|
27 |
|
residual ripple
|
10 % |
|
Voltage of external target value input [V]
|
0 to 10 |
|
Supply voltage, target value settings [V]
|
10 to 10.6 |
|
Supply current target value setting [mA]
|
6 to 6.36 |
|
Potentiometer external target value input [Kilo-Ohm]
|
2.5 to 10 |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Protection category
|
IP20 |
|
ambient temperature [°C]
|
0 to 60 |
|
Permission
|
C-tick |
|
Product weight [g]
|
80 |
|
Connection cross-section [mm²]
|
2,5 |
|
electrical connection:
|
Screw clamp |
|
Fastening type
|
With Slot rail |
|
Weight
|
80 g / Pcs |
|
GTIN
|
4052568184674 |
|
Customs duty number
|
90329000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet , Group data sheet: MPZ |
