Model series
|
D |
|
size
|
Maxi |
|
Construction set up
|
Fibre filter |
|
Filter porosity [Mikrometer]
|
0,01 |
|
Condensate drain
|
Fully automatic |
|
Operating pressure [bar]
|
2 to 12 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [6:8:4] |
|
Air purity class at the output
|
Compressed air to ISO 8573-1:2010 [1:7:2] |
|
Max. normal flow for air purity class [l/min]
|
2.200 |
|
Min. normal flow for air unit class [l/min]
|
480 |
|
Filter effective degree [%]
|
99,9999 |
|
Clamp protection
|
Metal protection basket |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
1.5 to 60 |
|
ambient temperature [°C]
|
-10 to 60 |
|
Residual oil content [Millgramm ]
|
0,01 |
|
Fastening type
|
pipe installation |
|
installation position
|
vertical ± 5° |
|
Pneumatic connection 1
|
G1 |
|
Pneumatic connection 2
|
G1 |
|
Housing material
|
Zinc pressure cast |
|
Filter material
|
Borosilicate fibre |
|
Clamps material
|
PC |
|
Material information
|
Copper and PTFE-free |
|
Product weight [g]
|
1.200 |
|
Weight
|
1.200 g / Pcs |
|
GTIN
|
4052568131968 |
|
Customs duty number
|
84213925 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Filters, D series (english) , Data sheet |
