ISO valve (size 1), 5/3-way, Centre position breathing, 230 V AC

برای مشاهده قیمت، ثبت نام کنید.

Materials:

Body and slider: aluminium, seals: NBR, pilot: polyamide (glass fibre reinforced)

Temperature range:

-10°C to +60°C

Media:

oiled and unoiled filtered compressed air

Switching time (at 5 bar):

< 40 ms

Control voltages:

Standard: 24 V=, 230 V AC, upon request: other voltages

Voltage tolerance:

± 10 %

Power consumption:

Direct current: 2.1 W, alternating current: 4,1 VA

Protection class (VDE 0470/EN 60529):

IP 65

Solenoid:

M (plug size 1)

Scope of delivery:

Valve including flange seal and fastening screws

Information:

These valves are generally delivered with coils and plugs!

Control voltage	230 V AC
function	Centre position breathing
ISO size	1
Operating pressure [bar]	2 - 10
flow [l/min]	1.500
Weight	550 g / Pcs
GTIN	4050571628925
Customs duty number	84812090
RoHS compliant	Yes
Manufacturer	YPC
YouTube Video	Directional valves - Overview, function and explanation of 5/3-way valves
