Construction set up
|
Piston pusher |
|
Actuation type
|
Manually |
|
Sealing principle
|
Soft |
|
Exhaust function
|
Cannot be throttled |
|
Hand assist actuation
|
none |
|
Valve function
|
3/2 bistable |
|
Operating pressure [bar]
|
0 to 16 |
|
C-value []
|
25,9 |
|
b-value
|
0.37 |
|
Normal nominal flow [l/min]
|
6.500 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Material information
|
RoHs compliant |
|
Medium temperature [°C]
|
-10 to 60 |
|
ambient temperature [°C]
|
-10 to 60 |
|
Maritime classification
|
see Certificate |
|
Fastening type
|
pipe installation |
|
installation position
|
arbitrary |
|
Flow direction
|
Not reversible |
|
Product weight [g]
|
796 |
|
Pneumatic connection 1
|
G1 |
|
Pneumatic connection 2
|
G1 |
|
Pneumatic connection 3
|
G3/8 |
|
Air purity class at the output
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium die casting |
|
Weight
|
796 g / Pcs |
|
GTIN
|
4052568012755 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: On-off/soft-start valves, D series (english) |
|
Document
|
Data sheet |
