Valve function
|
Throttle blowback function |
|
Pneumatic connection 1
|
G1/4 |
|
Pneumatic connection 2
|
G1/4 |
|
Setting element
|
knurled screw |
|
Fastening type
|
pipe installation |
|
Normal nominal flow in one-way flow control [l/min]
|
370,0 |
|
Normal nominal flow in check valve direction [l/min]
|
150 |
|
Operating pressure [bar]
|
0.5 to 10 |
|
ambient temperature [°C]
|
-20 to 75 |
|
Housing material
|
Aluminium wrought alloy |
|
installation position
|
arbitrary |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-20 to 75 |
|
Product weight [g]
|
80,0 |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Regulation screw material
|
Steel |
|
Normal flow In one-way flow control 6 -> 0 bar [l/min]
|
570 |
|
Normal flow In check valve direction 6 -> 0 bar [l/min]
|
340 |
|
Weight
|
80,0 g / Pcs |
|
GTIN
|
4052568000073 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: One-way flow control valves GR/GRA, in-line installation (english) |
|
Document
|
Data sheet |
