Stroke [mm]
|
10 |
|
Piston diameter
|
4 mm |
|
Dampening
|
No dampening |
|
installation position
|
arbitrary |
|
Construction set up
|
Piston |
|
Position detection
|
without |
|
Variants
|
One-sided piston rod |
|
Operating pressure [bar]
|
3.5 to 7 |
|
Principle of operation
|
Pressing |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
5 to 60 |
|
Theoretical force at 6 bar, flow [N]
|
4,9 |
|
Theoretical minimum spring rest force [N]
|
1,5 |
|
Theoretical maximum spring return force [N]
|
2,6 |
|
Product weight [g]
|
5 |
|
Fastening type
|
With locking nut |
|
Pneumatic connection
|
PK-2 |
|
Material information
|
RoHs compliant |
|
Cover material
|
High-alloyed steel |
|
Seals material
|
TPE-U(PU) |
|
Piston rod material
|
High-alloyed steel |
|
Cylinder tube material
|
Nickel-plated brass |
|
Weight
|
5 g / Pcs |
|
GTIN
|
4052568066680 |
|
Customs duty number
|
84123100 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: EG (english) , Data sheet |
