size
|
20 |
|
Stroke [mm]
|
8 |
|
Dampening
|
self-adjusting |
|
installation position
|
arbitrary |
|
Position detection
|
without |
|
Max. impact speed [m/s]
|
1,5 |
|
Rest time short [s]
|
0,2 |
|
Rest time long [s]
|
1 |
|
Principle of operation
|
Pressing |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
-10 to 80 |
|
Dampening length [mm]
|
8 |
|
Max. impact force [N]
|
500 |
|
Max. tightening torque [Nm]
|
5,0 |
|
Max. energy consumption per stroke [J]
|
3,0 |
|
Max. energy consumption per hour [J]
|
18.000 |
|
Max. residual energy [J]
|
0,020 |
|
Reset force [N]
|
2,5 |
|
Product weight [g]
|
30,0 |
|
Fastening type
|
With locking nut |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Housing material
|
High-alloyed steel |
|
Piston rod material
|
High-alloyed steel |
|
Weight
|
30,0 g / Pcs |
|
Customs duty number
|
84879059 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Cushioning components (english) , Data sheet |
