Permitted cable diameter [mm]
|
7 to 13 |
|
Based on standard
|
EN 60947-5-1 |
|
Design
|
round |
|
installation position
|
arbitrary |
|
Short circuit resistance
|
no |
|
Switching element function
|
changeover contact |
|
Reverse polarity protection
|
no |
|
Measurement principle
|
Mechanical / electrical |
|
Switching position display
|
yes |
|
Operating voltage range AC [V]
|
4 to 250 |
|
Operating voltage range DC [V]
|
4 to 250 |
|
Intrinsic power input at operating voltage [mA]
|
1 to 5000 |
|
Insulation voltage [V]
|
250 |
|
Max. output current [mA]
|
5.000 |
|
Minimum load current
|
1 mA at 4 V/DC |
|
Surge voltage strength [kV]
|
2,5 |
|
Degree of contamination
|
3 |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Protection category
|
IP67 |
|
ambient temperature [°C]
|
-20 to 70 |
|
electrical connection:
|
Screw clamp |
|
Cable screwing
|
M20x1,5 |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Housing cover material
|
PC |
|
Housing socket material
|
ABS+PC |
|
Console material
|
ABS+PC |
|
Weight
|
480 g / Pcs |
|
GTIN
|
4052568168117 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: DAPZ (english) , Data sheet |
