Dimensions W x L x H
|
27 mm x 123 mm x 40 mm |
|
Pitch dimension [mm]
|
28 |
|
Quantity outputs:
|
0 |
|
Quantity inputs
|
8 |
|
Diagnosis via LED
|
Error per module |
|
Input debouncing time
|
0.1 ms |
|
Fuse (short circuit)
|
Internal electronic fuse |
|
Intrinsic power input operating voltage electronics/sensors
|
typically 12 mA |
|
Nominal operating voltage DC electronics / sensor [V]
|
24 |
|
Nominal operating voltage DC [V]
|
24 |
|
Potential separation channel - internal bus
|
no |
|
Potential separation channel - channel
|
no |
|
Switch level
|
Signal 0: <= 5 V |
|
Permitted voltage oscillations electronics/sensors
|
± 25 % |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Oscillation strength
|
Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
|
Shock resistance
|
Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
-20 to 40 |
|
Medium temperature [°C]
|
-5 to 50 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
75 |
|
Characteristic curves inputs
|
to IEC 61131-2 type 3 |
|
Max. line length
|
30 m |
|
Switching logic inputs
|
PNP (Positive switching) |
|
Electrical connection: input, function
|
Digital input |
|
Electrical connection: input, connection type
|
8x socket |
|
Electrical connection: input, connection technology
|
M8x1 A coded to EN 61076-2-104 |
|
Electrical connection: input, number of pins / wires
|
3 |
|
Material information
|
RoHs compliant |
|
Housing material
|
PA reinforced |
|
Weight
|
75 g / Pcs |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VTEM (english) , Data sheet |
