Dimensions W x L x H
|
100 mm x 110 mm x 130 mm |
|
Parameterising
|
Systemparameter |
|
Additional functions
|
Systemstatus über Prozessdaten abbildbar |
|
Operating element
|
DIL switch |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 90 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
1.255,0 |
|
Max. address volume outputs [Byte]
|
12 |
|
Max. address volume inputs [Byte]
|
12 |
|
Report
|
Interbus |
|
Material information
|
RoHs compliant |
|
Housing material
|
Aluminium |
|
Fieldbus interface
|
(Rugged line FO conn. ,input) |
|
Device specific diagnosis
|
Unterspannung Module |
|
Baud rate
|
500, 2000 kBit/s |
|
LED display bus specific
|
FO1: Fiber Optic 1 |
|
LED display product specific
|
SF: System error |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Weight
|
1.255,0 g / Pcs |
|
GTIN
|
4052568218263 |
|
Customs duty number
|
85176200 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) , Data sheet |
