Dimensions W x L x H
|
50 mm x 107 mm x 55 mm |
|
Diagnosis
|
Unterspannung |
|
Operating element
|
DIL switch |
|
LED displays
|
1 Failsafe-Protokoll aktiv |
|
Operating voltage range DC [V]
|
20.4 to 28.8 |
|
Intrinsic power input at operating voltage
|
Type 35 mA For electronics |
|
Nominal operating voltage DC [V]
|
24 |
|
Potential separation channel - channel
|
no |
|
Corrosion resistant class KBK
|
(In integrated condition) |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
Depends on connection block |
|
ambient temperature [°C]
|
-5 to 50 |
|
Max. address volume outputs [Byte]
|
7 |
|
Max. address volume inputs [Byte]
|
6 |
|
Max. line length
|
200 m |
|
Material information
|
RoHs compliant |
|
Quantity inputs
|
8 |
|
Characteristic curves inputs
|
to IEC 61131-2 type 2 |
|
Switching logic inputs
|
PNP (Positive switching) |
|
Safety function
|
Safe recording and analysis of input conditions |
|
Safety Integrity Level (SIL)
|
Safe recording and analysis of input conditions according to EN62061 to SIL CL3 |
|
Performance Level (PL)
|
Safe recording and analysis of input conditions according to ISO13849 to Cat.4 and PL e |
|
Max. cumulative currents per module [A]
|
3 |
|
residual ripple
|
2 Vss within voltage range |
|
Certified awarding point
|
01/205/5444.00/15 |
|
CE certificate (see declaration of conformity)
|
to EU machinery directive |
|
Permission
|
c UL us - Recognized (OL) |
|
Probability of Failure per Hour in [1/h].
|
1e-009 |
|
Weight
|
175 g / Pcs |
|
Customs duty number
|
85389091 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) , Data sheet |
