Dimensions W x L x H
|
50 mm x 107 mm x 55 mm |
|
Diagnosis
|
Modulorientierte Diagnose |
|
Max. number of modules
|
10 |
|
Display
|
Seven segment display |
|
Operating element
|
3 buttons |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Load voltage range DC [V]
|
20 to 30 |
|
Nominal operating voltage DC [V]
|
24 |
|
Nominal load voltage DC [V]
|
24 |
|
Power input in nominal operating voltage [mA]
|
80 |
|
Permitted load current [A]
|
2,5 |
|
Continuous impact strength DIN&EC 68 parts 2-29
|
Tested to severity class 2 |
|
Relative humidity
|
5 - 95 % |
|
Protection category
|
IP65 |
|
Oscillation strength to DIN/IEC 68 part 2-6
|
Tested to severity class 2 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
140 |
|
Axes per strand
|
1 |
|
Quantity axis strands
|
1 |
|
Electrical connection: control interface
|
M9 |
|
Cable length [MTR]
|
<= 30 m |
|
Control interface
|
Digital |
|
Housing material
|
PA reinforced |
|
Weight
|
140 g / Pcs |
|
GTIN
|
4052568190231 |
|
Customs duty number
|
85371091 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
|
Document
|
Group data sheet: CPX-CMPX |
