Dimensions W x L x H
|
50 mm x 107 mm x 55 mm |
|
Diagnosis
|
Channel and modulated diagnosis |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Nominal operating voltage DC [V]
|
24 |
|
Power blackout bridging [ms]
|
10 |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
140,0 |
|
Max. line length
|
30 m |
|
Material information
|
RoHs compliant |
|
Housing material
|
PA reinforced |
|
Device specific diagnosis
|
Under-voltage measuring system |
|
Permission
|
C-tick |
|
Relative humidity
|
5 - 95 % |
|
Control interface
|
Digital |
|
Short circuit resistance
|
yes |
|
Max. number of modules
|
9 |
|
Display
|
Seven segment display |
|
Status displays
|
LED yellow = PL (Power Load) |
|
Power input in nominal operating voltage [mA]
|
80 |
|
Axes per strand
|
1 |
|
Quantity axis strands
|
1 |
|
Electrical connection: control interface
|
M9 |
|
Weight
|
140,0 g / Pcs |
|
GTIN
|
4052568215347 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX-CMIX (english) , Data sheet |
