Dimensions W x L x H
|
50 mm x 107 mm x 50 mm |
|
Diagnosis
|
Kurzschluss/Überlast pro Kanal |
|
Parameterising
|
Eingangsentprellzeit |
|
LED displays
|
1 Sammeldiagnose |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 15 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Potential separation channel - internal bus
|
no |
|
Potential separation channel - channel
|
no |
|
Corrosion resistant class KBK
|
(In integrated condition) |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
Depends on connection block |
|
ambient temperature [°C]
|
-5 to 50 |
|
Housing material
|
PC |
|
Quantity inputs
|
8 |
|
Input debouncing time
|
3 ms (0.1 ms, 10 ms, 20 ms parameterisable) |
|
Fuse (short circuit)
|
Internal electronic fuse Per channel |
|
Max. cumulative current inputs per module [A]
|
0,7 |
|
Switch level
|
Signal 0: <= 5 V |
|
Characteristic curves inputs
|
IEC1131-T2 |
|
Switching logic inputs
|
PNP (Positive switching) |
|
Weight
|
110 g / Pcs |
|
GTIN
|
4052568008086 |
|
Customs duty number
|
85389091 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) |
|
Document
|
Data sheet |
