CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
KC-mark
|
KC-EMV |
|
Permission
|
C-tick |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Fastening type
|
With throughway bores |
|
Housing material
|
PA reinforced |
|
Material information
|
RoHs compliant |
|
LED displays
|
16 Kanalstatus |
|
Fuse (short circuit)
|
Internal electronic fuse Per group |
|
Operating voltage DC load voltage [V]
|
24 |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Input debouncing time
|
3 ms (0.5 ms, 10 ms, 20 ms parameterisable) |
|
Max. cumulative currents per module [A]
|
0,7 |
|
Max. number of inputs
|
16 |
|
Nominal operating voltage DC [V]
|
24 |
|
Potential separation channel - channel
|
no |
|
Residual ripple load voltage
|
4 Vss |
|
Switch level
|
Signal 0: <= 6 V |
|
Characteristic curves inputs
|
IEC1131-T2 |
|
Switching logic inputs
|
PNP (Positive switching) |
|
Cover material
|
PA reinforced |
|
Weight
|
280 g / Pcs |
|
GTIN
|
4052568185565 |
|
Customs duty number
|
85389099 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPI (english) , Data sheet |
