Integration depth [mm]
|
34 |
|
Height [mm]
|
89 |
|
Length [mm]
|
125 |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Relative humidity
|
5 - 85 % |
|
Protection category
|
IP20 |
|
ambient temperature [°C]
|
0 to 50 |
|
Permission
|
C-tick |
|
Product weight [g]
|
230 |
|
Material information
|
RoHs compliant |
|
Digital inputs, quantity
|
20 |
|
Digital inputs, quick number inputs
|
2 |
|
Digital inputs, incremental encoder connection
|
2 |
|
Digital inputs, input signal delay
|
0.1 ms |
|
Digital inputs, input voltage / current
|
24 VDC |
|
Digital inputs, nominal value for TRUE
|
12 - 30 VDC |
|
Digital inputs, nominal value for FALSE
|
0 V |
|
Digital inputs, potential separation
|
yes |
|
Analogue inputs, quantity
|
4 |
|
Analogue inputs, resolution
|
12 bit |
|
Analogue inputs, signal range
|
0 - 10 V |
|
Analogue inputs, Absolute precision at 25 °C
|
0.1 % |
|
Analogue inputs, linearity error at 25 °C
|
0,1% FS |
|
Analogue inputs, input resistance [Ohm]
|
47 |
|
Digital outputs, quantity
|
12 |
|
Digital outputs, output voltage
|
12 - 30 VDC |
|
Digital outputs, output current
|
0.5 A |
|
Digital outputs, potential separation
|
yes |
|
Digital outputs, short circuit proof
|
yes |
|
Digital outputs, overload resistant
|
yes |
|
Analogue outputs, quantity
|
4 |
|
Analogue outputs, resolution
|
12 bit |
|
Analogue outputs, max. load resistance [Ohm]
|
470 |
|
Analogue outputs, signal range
|
± 10 V |
|
Analogue outputs, linearity error at 25 °C
|
± 0.2% |
|
Weight
|
230 g / Pcs |
|
GTIN
|
4052568223960 |
|
Customs duty number
|
85389099 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CDPX (english) , Data sheet |
