Materials:
shock absorber body and accessory: Steel bronzing, piston rod: hard chromium-plated steel, head: hardened and bronzed steel, compression spring: zinc plating or KU-coated
Temperature range:
-12°C to max. +66°C
Stroke speed:
0.15 - 5 m/s (upon request, up to 20 m/s)
Fixed limit stop:
integrated
Optional:
High temperature version (0°C up to max. +150°C)
, low temperature version (-50°C up to max. +66°C)
| عنوان ویژگی |
مقدار ویژگی |
|
Version
|
self-adjusting |
|
max. Energy consumption per stroke (W3) [Nm]
|
3.730 |
|
max. Energy consumption per hour (W4) [Nm]
|
192.000 |
|
effective mass (me) [KGM]
|
270 - 1100 |
|
Spring force [N]
|
105 - 270 |
|
Thread A
|
M 64 x 2 |
|
Max. axial deviation* [°]
|
3 |
|
B [mm]
|
226,6 |
|
C [mm]
|
99,4 |
|
Ø D [mm]
|
48 |
|
Stroke [mm]
|
100 |
|
Impact head
|
|
|
clamping flange
|
|
|
Locking nut
|
|
|
Temperature range [°C]
|
-12 to +66 |
