Materials:
shock absorber body and accessory: Steel bronzing, piston rod: hard chromium-plated steel, head: hardened and bronzed steel, compression spring: zinc plating or KU-coated
Temperature range:
-12°C to max. +66°C
Stroke speed:
0.15 - 5 m/s (upon request, up to 20 m/s)
Fixed limit stop:
integrated
Optional:
High temperature version (0°C up to max. +150°C)
, low temperature version (-50°C up to max. +66°C)
| عنوان ویژگی |
مقدار ویژگی |
|
Version
|
self-adjusting |
|
max. Energy consumption per stroke (W3) [Nm]
|
1.130 |
|
max. Energy consumption per hour (W4) [Nm]
|
146.000 |
|
effective mass (me) [KGM]
|
790 - 3140 |
|
Spring force [N]
|
50 - 180 |
|
Thread A
|
M 45 x 1.5 |
|
Max. axial deviation* [°]
|
2 |
|
B [mm]
|
172,1 |
|
C [mm]
|
73,9 |
|
Ø D [mm]
|
35 |
|
Stroke [mm]
|
75 |
|
Impact head
|
|
|
clamping flange
|
|
|
Locking nut
|
|
|
Temperature range [°C]
|
-12 to +66 |
