Materials:
Body and slider: aluminium, seals: NBR, pilot: polyamide (glass fibre reinforced)
Temperature range:
-10°C to +60°C
Media:
oiled and unoiled filtered compressed air
Switching time (at 5 bar):
< 35 ms
Control voltage:
Standard: 24 V=, 230 V AC, upon request: other voltages
Voltage tolerance:
± 10 %
Power consumption:
Direct current: 2.5 W, alternating current: 3.5 VA (60 Hz)
Protection class (VDE 0470/EN 60529):
IP 65, plug size 0
Optional:
Control voltages 12 V=
, 24 V AC
, 115 V AC
Information:
These valves are generally delivered with coils and plugs!
|
Control voltage
|
230 V AC |
|
centre position
|
ventilated |
|
Thread
|
G 1/4" (G 1/8") |
|
Operating pressure [bar]
|
2 - 10 |
|
flow [l/min]
|
690 |
|
Weight
|
270 g / Pcs |
|
GTIN
|
4050571612467 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
YPC |
